Periodic Table

Hafnium

Transition Metal

Quick Facts about Hafnium

Lu
  • solid- state of matter at room temperature
  • Stable- has at least one stable isotope
  • +4- common oxidation states in compounds
  • HEX- crystal structure, atomic arrangement in solid form
Ta

Hafnium (Hf) is element 72 on the periodic table. Atomic mass of Hf: 178.4900 u. Hf is in period 6, group 4. Melting point of Hf: 2506.00 K.Density of Hf: 13.31 g/cm³.

Why Hafnium Matters

Hafnium in everyday life and industry

In Your Home

  • Modern computer chips use hafnium oxide as a gate insulator
  • Plasma cutting torches use hafnium electrodes

Industry Uses

NuclearNuclear submarine control rods contain hafnium
MetallurgySuperalloys for jet engines contain small amounts of hafnium

In Your Body

✗ Not essential

Hafnium has no known biological role. Hafnium powder is pyrophoric (ignites spontaneously in air). Very little research exists on hafnium's biological effects.

Safety: The metal is generally considered non-toxic

Discovery of Hafnium

Discovered by Dirk Coster, Georg von Hevesy in Denmark, 1923

Name origin: From Hafnia, the Latin name of Copenhagen.

History & Events

1923
Named after Hafnia, the Latin name for Copenhagen
1923
Last naturally occurring stable element to be discovered (1923)
1923
Discovery confirmed Bohr's atomic theory predictions
1923
Separated from zirconium only after Bohr predicted where to look

About Hafnium

Silvery lustrous metallic transition element. Used in tungsten alloys in filaments and electrodes, also acts as a neutron absorber. First reported by Urbain in 1911, existence was finally established in 1923 by D. Coster, G.C. de Hevesy in 1923.

Atomic Properties of Hf

Atomic Number of Hf
72
Atomic Mass of Hf
178.4900 u
Electron Configuration
[Xe] 4f14 5d2 6s2
Electronegativity
1.30
Block
d-block
Group
4
Period
6

Physical Properties of Hf

Phase (STP)
solid
Melting Point of Hf
2506.00 K
Boiling Point of Hf
4876.00 K
Density of Hf
13.3100 g/cm3

Thermal Properties

Heat of Fusion
25.10 kJ/mol
Heat of Vaporization
575.00 kJ/mol
Specific Heat
0.14 J/g·K
Molar Heat Capacity
25.73 J/mol·K
Thermal Conductivity
23.00 W/m·K

Atomic Radii

Calculated
155 pm
Covalent
152 pm
Van der Waals
223 pm
Metallic
144 pm

Common Misconceptions

Wrong:Hafnium is extremely rare.
Correct:At 3 ppm in Earth's crust, hafnium is more abundant than silver or mercury. It seems rare because it's always found with zirconium and is difficult to separate.
Wrong:Hafnium was discovered through random mineral analysis.
Correct:Bohr predicted element 72 would be a transition metal (not a rare earth) based on his atomic theory. Coster and Hevesy found it in zirconium ores exactly where Bohr said to look.
Wrong:Computer chips use metallic hafnium.
Correct:Intel's 2007 'hafnium revolution' used HfO2 (hafnium dioxide) as a high-κ gate dielectric, replacing SiO2 to reduce transistor leakage at nanometer scales.

Isotopes of Hafnium

Hafnium has 6 naturally occurring isotopes, plus 1 notable radioactive isotope.

IsotopeAtomic Mass (u)AbundanceHalf-LifeDecay Mode
17472Hf (Hf-174)Hafnium-174 isotope173.94004610.1600%
17672Hf (Hf-176)Hafnium-176 isotope175.94140765.260%
17772Hf (Hf-177)Hafnium-177 isotope176.943227718.60%
17872Hf (Hf-178)Hafnium-178 isotope177.943705827.28%
17972Hf (Hf-179)Hafnium-179 isotope178.945823213.62%
18072Hf (Hf-180)Hafnium-180 isotope179.94655735.08%
18272Hf (Hf-182)Hafnium-182 isotope181.95056120%8.9 million yearsβ⁻

Data source: NIH PubChem (aggregated from IUPAC, NIST)

Isotope Applications

Isotopes of Hafnium have important real-world applications in science and industry.

Geochronology & Dating

Some 176Hf is radiogenic as a result of it being formed as a product of beta decay of radioactive 176Lu (half-life of 3.73×1010 years) [301]. Thus, relations between the isotope-amount ratiosn(176Hf)/n(177Hf) and n(176Hf)/n(176Lu) have been used to determine the ages of minerals and rocks. Because of the long half-life of 176Lu, these ratios have been used in geochronology studies that document some of the oldest rocks in the Solar System and on Earth (Fig. IUPAC.72.1). Hafnium isotopic compositions of terrestrial materials evolved differently depending on the relative rates of 176Hf production. Geologists can use calculated lutetium-hafnium ages and the initial isotope-amount ratio n(176Hf)/n(177Hf) along with other isotopic data from the oldest rocks in the Earth to infer that the Earth’s crust differentiated within the first few hundred million years after condensation of the oldest solid matter in the Solar System [502]. Radioactive 182Hf decays to 182W with a half-life of 8.9×106 years, which is much less than the age of meteorites and the Earth. Therefore, measurements of the amounts of hafnium and tungsten isotopes in meteorites and terrestrial samples reveal the earlier presence of 182Hf. As a result, this provides information about chemical differentiation and evolution of the early Solar System [503], [504].

Abundance

Earth's Crust
3.0 mg/kg
Seawater
7.00×10-6 mg/L

Uses

Used in reactor control rods because of its ability to absorb neutrons.

Sources

Obtained from mineral zircon or baddeleyite.

Geochemistry

Goldschmidt
litophile
Geochemical Class
high field strength
